Evaluate this design for your project
Use these notes to prepare a specification for the intended contents and filling process. The illustration and reference entries are not product test results. Learn about Unique Packaging and discuss the final specification with our team.
Review the liquid and filling route
Identify the drink, fill temperature, viscosity and storage conditions. Confirm how it will enter and leave the pack, including any cap or straw opening. Test the proposed filled pack for leakage and handling; beverage artwork does not establish hot-fill, carbonation or retort suitability.
Match the fitment to filling and dispensing
Confirm spout position, neck dimensions, cap and filling route. For dry contents, check opening clearance and flow rather than applying a liquid-fill assumption. Request a fitment drawing and a filled sample that match the intended pack.
Review the spout assembly
Request the neck, cap and opening drawing and confirm the filling route. Check dispensing access, cap handling and leakage in a filled sample. The fitment position must match the approved dieline.
Resolve the material references
The material and film entries describe different levels of detail or alternative options. Choose one final layer structure in the quotation; do not combine the lists into an assumed laminate. Confirm layer order, thicknesses, sealant and the testing needed for the intended contents.
Confirm size and measurement basis
The volume reference is 50ml,200ml,500ml,1000ml,2000ml. Confirm usable internal dimensions and test the intended fill quantity with the actual contents; weight, volume and flat dimensions are not interchangeable.
Approve the artwork and print route
Share artwork status, the number of designs and quantity per design. Ask the quotation to identify the selected printing and finishing processes rather than assuming every listed reference applies. Approve the dieline, color proof and clear seal areas before production.
Compare specification alternatives
Compare the recorded options for UPS-0143 with the references below. A matching appearance or material name does not establish that two structures are interchangeable.
Differences from UPS-0143| Design reference | Option-by-option comparison |
|---|
| UPS-0056: Juice & Drink Spout Pouch | Film / laminate reference
UPS-0143: PET/PA/AL/PE
UPS-0056: BOPP, PET/OPP/VMPET/LLDPE
Material reference
UPS-0143: PET/NY/AL/PE
UPS-0056: PET/OPP/VMPET/LLDPE, NY/PE
Opening & closure
UPS-0143: Spout assembly (position and cap to be confirmed)
UPS-0056: Opening and closure to be specified |
|---|
| UPS-0058: Fruit Juice Spout Pouch | Film / laminate reference
UPS-0143: PET/PA/AL/PE
UPS-0058: PA/NY
Material reference
UPS-0143: PET/NY/AL/PE
UPS-0058: Not specified
Thickness reference
UPS-0143: Not specified
UPS-0058: 0.2 mm (measurement basis to be confirmed) |
|---|
| UPS-0060: Fruit Juice Spout Pouch | Film / laminate reference
UPS-0143: PET/PA/AL/PE
UPS-0060: BOPP; separate reference: PET/OPP/VMPET/LLDPE
Material reference
UPS-0143: PET/NY/AL/PE
UPS-0060: Not specified
Print references
UPS-0143: Gravure printing / Pad printing
UPS-0060: Gravure printing / Screen printing / Pad printing |
|---|
